We provide Façade BIM, VDC, and CAD services that transform design intent into accurate, coordinated, and fabrication-ready façade models. Our team develops detailed 3D façade models, shop drawings, curtain wall detailing, glazing layouts, ACP panel drawings, skylight details, and quantity take-offs—aligned with your system specifications, profiles, tolerances, and project standards. With experienced façade engineers and a structured QC workflow, we ensure precision, consistency, and clear coordination with structural and architectural models.
Our BIM-led façade workflow enables early clash detection, refined panelization, and better visualization than traditional 2D methods. Profiles, brackets, joints, fixing details, and material layouts are all generated from the same coordinated model, helping reduce installation errors, improve constructability, and streamline fabrication. From concept through shop drawings and installation support, our façade BIM services deliver smooth and predictable project execution.
Our Façade BIM / VDC Services
Façade BIM
Façade BIM provides accurate 3D modeling of curtain walls, glazing systems, cladding, fins, louvers, skylights, and façade support structures. Models include profiles, brackets, anchors, joints, and tolerances needed for coordination and documentation. This digital environment simplifies design reviews, improves clash detection, and enhances installation planning.
Facade Shop Drawings
Façade Shop Drawings include elevations, plans, sections, profiles, bracket details, anchor details, gasket layouts, material specifications, and installation sequences. These drawings are extracted from the coordinated model, ensuring accuracy during fabrication and site installation.
Unitized Curtainwall Detailing
Unitized Curtain Wall Detailing covers panel assembly, mullion–transom connections, unit joints, glazing infills, anchors, brackets, and sealing details. Each unit is modeled and detailed to match fabrication standards, streamlining production, quality checks, and installation
Curtain Wall Detailing
Curtain Wall Detailing includes stick system layouts, profile details, pressure plates, caps, gaskets, fasteners, and glass installation details. All components are modeled with correct tolerances, enabling shop drawings and support documentation to be generated directly from the model.
Spider Glazing
Spider Glazing services include 3D modeling and detailing of glass panels, spider fittings, fin supports, point-supported hardware, bolt patterns, and bracket systems. Models and drawings ensure precise alignment and smooth installation of point-fixed façade systems.
Skylight Detailing
Skylight Detailing includes rafters, purlins, glazing units, joints, seals, support brackets, and drainage details. The coordinated 3D model helps ensure proper slope, drainage, and fit during installation.
ACP (Aluminum Composite Panel) Detailing
ACP Detailing covers panel layouts, cutting patterns, bending details, joint arrangements, fixing systems, fasteners, sealants, and edge conditions. Panels are numbered and organized for fabrication and quick on-site assembly.
Glazing Shop Drawings
Glazing Shop Drawings include glass sizes, thicknesses, edge conditions, brackets, channels, pressure plates, silicone joints, and installation details. All glazing data is derived from the coordinated façade model.
Shop Front Drawings
Shop Front Drawings provide accurate detailing for storefronts, including frames, mullions, transoms, signage supports, glazing, and door assemblies. These drawings follow project standards and suit both fabrication and installation requirements.
Quantity Take-Off
Façade Quantity Take-Off delivers accurate material quantities for glass, ACP panels, aluminum profiles, brackets, anchors, and hardware. Quantities are extracted directly from the façade model and organized according to your reporting format.
2D Drafting
2D Drafting services provide clean and accurate CAD drawings for façades, including sections, elevations, details, and fabrication drawings. All drawings follow your layer standards, templates, and presentation styles.
